Lightweight plastic push-in connectors used on the low-pressure secondary feeder lines of single-line and progressive lubrication systems — particularly suited to fast field installation and minor on-site repairs.

Features

• Tool-free installation — push-to-connect with internal collet seal
• Tube sizes: 4 mm, 6 mm, 8 mm OD nylon or polyurethane
• Working pressure: up to 10 bar — appropriate for secondary feeder lines after the divider, not for high-pressure mains
• Food-grade variants available for beverage, food-processing and pharmaceutical lubrication

When to specify

For temporary installations, prototype builds, or any feeder line downstream of a progressive divider where pressures are reduced and rapid serviceability matters more than ultimate pressure rating. For high-pressure runs, specify our compression-fitting range instead.
